IC+ Series Pumps
AMPCO IC+ SERIES INDUSTRIAL CENTRIFUGAL PUMPS
Harco presents the Ampco IC+ Series of industrial centrifugal pumps, providing a cost-efficient solution for industrial settings where cast iron pumps aren’t suitable. This pump, designed for non-sanitary applications, is derived from the highly regarded Ampco AC/AC+ Series of sanitary pumps, ensuring matching hydraulic performance and external dimensions.
Constructed of 316L stainless steel, Ampco’s IC+ Series industrial centrifugal pumps feature a beaded finish fluid end and comes with a 304 stainless steel adapter. These pumps are equipped with a standard Type 21 single mechanical seal and typically use NPT (National Pipe Thread) or flange fittings for connections.
Some of the most common applications for the Ampco IC+ industrial centrifugal pump series include grey water processing and in-plant booster pumps for non-sanitary water supply.
Features of the Ampco IC+ Series Industrial Centrifugal Pumps:
- Cost Effective
- Simple Maintenance Friendly Design
- Internal Type 21 Single Mechanical Seal which Promotes Cooling
- 316L Stainless Steel Construction
- 304 Stainless Steel Adapter
- Dynamically Balanced Impeller
- Multiple Fitting Options – NPT, Flange
Performance Overview of the Amcpo IC+ Series Pumps:
Models: 10
Max Discharge Pressure: 60 PSI / 4 BAR
Max Flow Rate: 920 GPM / 209 mᵌ/hr
Max Viscosity: 1,200 cP
Contact Harco for your Ampco IC+ Pump or IC+ replacement part inquires.
For more information contact us at 1-800-361-5361 or 705-743-5361, or [email protected]
SPARE PARTS
Ampco IC+ Seal Kits
| Model | Shaft Size | Type | Part Number | Description |
| IC+ 114 /IC+ 214 | 3/4″ | 21 | GS8101100 | Ceramic seat vs. carbon (Buna) |
| IC+ 114 /IC+ 214 | 3/4″ | 21 | GS8101101 | Ceramic seat vs. carbon (Viton) |
| IC+ 114 /IC+ 214 | 3/4″ | 21 | GS8101103 | Silicon carbide seat vs. carbon (Viton) |
| IC+ 114 /IC+ 214 | 3/4″ | 21 | GS8101104 | Silicon carbide seat vs. silicon carbide (Viton) |
| IC+ 216/IC+ 316 | 1-1/8″ | 21 | GS8101200 | Ceramic seat vs. carbon (Buna) |
| IC+ 216/IC+ 316 | 1-1/8″ | 21 | GS8101201 | Ceramic seat vs. carbon (Viton) |
| IC+ 216/IC+ 316 | 1-1/8″ | 21 | GS8101203 | Silicon carbide seat vs. carbon (Viton) |
| IC+ 216/IC+ 316 | 1-1/8″ | 21 | GS8101204 | Silicon carbide seat vs. silicon carbide (Viton) |
| IC+ 218 / 328 & IC+ 318 / 428 | 1-1/2″ | 21 | GS8101300 | Ceramic seat vs. carbon (Buna) |
| IC+ 218 / 328 & IC+ 318 / 428 | 1-1/2″ | 21 | GS8101301 | Ceramic seat vs. carbon (Viton) |
| IC+ 218 / 328 & IC+ 318 / 428 | 1-1/2″ | 21 | GS8101303 | Silicon carbide seat vs. carbon (Viton) |
| IC+ 218 / 328 & IC+ 318 / 428 | 1-1/2″ | 21 | GS8101304 | Silicon carbide seat vs. silicon carbide (Viton) |
| IC+ 4410/ IC+ 6410 | 1-3/4″ | 21 | GS8101400 | Ceramic seat vs. carbon (Buna) |
| IC+ 4410/ IC+ 6410 | 1-3/4″ | 21 | GS8101401 | Ceramic seat vs. carbon (Viton) |
| IC+ 4410/ IC+ 6410 | 1-3/4″ | 21 | GS8101403 | Silicon carbide seat vs. carbon (Viton) |
| IC+ 4410/ IC+ 6410 | 1-3/4″ | 21 | GS8101404 | Silicon carbide seat vs. silicon carbide (Viton) |
Mechanical Seal Replacement Kits Include: Mechanical Seal, casing gasket, and impeller nut gaskets (2).
